Description
- High efficiency solar cells
- Low iron tempered glass with anti-reflection coating and high transmission rate.
- Aluminium frame: Easy to install.
- Superior Multi-function junction box with water proof capabilities.
- Long lifespan
- Weather proof
- Resistant to moisture and etching. Not affected by geology.
| Model | JA545W |
| Maximum Power (Pm) | 545W |
| Open Circuit Voltage (V) | 49.75V |
| Short-Circuit Current (Isc) | 13.93A |
| Maximum Power Current (Vmp) | 13.04V |
| Power Tolerance | 0~+5W |
| Maximum System Voltage | 1500V DC |
| Module Application Class |
Class A |
| Nominal Operating Temperature | 45±2◦C |
| Operating Temperature | -40◦C~ +85◦C |
